Description
Sigineer Power is proud to introduce you the cutting edge M3048NC, 3KW 48Vdc 120Vac, with 80A MPPT Solar charger and 40A AC charger with stacking capacity.
It contains a 80A MPPT solar charger and a utility AC charger.
Its versatile stacking feature allows the 120Vac units to be stacked together to
1 increase output power up to 18KW at 120Vac
2 create 120/240v split phase from two 120Vac units
3 create 120/208Vac three phase from three 120Vac units
The highly programmable LCD menu allows users to set a wide range of inverter specs such as
1 AC output Frequency :50hz or 60hz
2 Power priority: Solar, battery, or Utility
3 Ac Input voltage range
4 Charging current & voltage
5 Power saver mode
6 Auto restart after overload or overtemp
7 Enable/Disable neutral to ground bonding.
It virtually allows users to change all of its spec within its range.
FEATURES
•Built-in 60-145Vdc 80A MPPT solar charge controller with 60A AC charger
•High frequency transformer-less compact design & lightweight
•Pure sine wave AC 100V 110V 120V output with 50hz/60hz switch
•Parallel operation for 120V/240V split phase or 120/208V three phase output
•Parallel operation up to 6 units
•Optional WiFi/ GPRS remote monitoring
•Optional RS485 communication with BMS (battery management system)
•Overload, short circuit, over discharge, battery reverse protection
•Dry Contacts for delivering signal about inverter operation status
SPECIFICATIONS
High Frequency Off Grid Solar Inverter Charger Spec Sheet
| MODEL # | M3024NC | M3048NC | M3048BP | M5000H-48BP |
|---|---|---|---|---|
| Rated Power | 3000VA/3000W | 3000VA/3000W | 3000VA/3000W | 5000VA/5000W |
| Parallel Capability | Up to 6 units for split phase or three phase | |||
| Remote Monitoring | WiFi | WiFi | WiFi | WiFi |
| Remote Monitoring | GPRS | GPRS | GPRS | GPRS |
| AC Input Voltage | 110/120 VAC | 110/120 VAC | 110/120 VAC | 220/230/240 VAC |
| AC Input Voltage Range | 60-140Vac | 60-140Vac | 60-140Vac | 90-280Vac |
| Ac Input Frequency Range | 50 Hz/60 Hz (Auto sensing) | |||
| AC Voltage Regulation (Batt. Mode) | 110/120 VAC ± 5% | 110/120 VAC ± 5% | 110/120 VAC ± 5% | 220/230/240 VAC ± 5% |
| AC Input Breaker | 40A | 40A | 40A | 40A |
| AC Output Bypass Breaker | 40A | 40A | 40A | 40A |
| Nominal AC Output Power | 3000VA/3000W | 3000VA/3000W | 3000VA/3000W | 5000VA/5000W |
| Surge AC Output Power | 6000W (5 secs) | 6000W (5 secs) | 6000W (5 secs) | 10000W (5 secs) |
| DC To AC Efficiency (Peak) | 0.93 | 0.93 | 0.9 | 0.93 |
| Transfer Time | 10 ms(For Personal Computers) ; 20 ms(For Home Appliances) | |||
| Output Waveform | Pure Sine Wave | |||
| Battery Voltage | 24 VDC | 48 VDC | 48 VDC | 48 VDC |
| CV & Float Charge voltage | 24.0V~29.2V Settable | 48.0V~58.4V Settable | 48.0V~58.4V Settable | 48.0V~58.4V Settable |
| Maximum PV Array Power | 4500W | 4500W | 4000W | 4500W |
| MPPT Range @ Operating Voltage | 30~115 VDC | 60~115 VDC | 120~250 VDC | 120~430 VDC |
| Maximum PV Array Open Circuit Voltage | 145 VDC | 145 VDC | 250 VDC | 450 VDC |
| Maximum Solar Charge Current | 80 A | 80 A | 80 A | 100 A |
| Maximum AC Charge Current | 60 A | 40 A | 40 A | 80 A |
| Maximum Charge Current(PV+AC) | 140 A | 120 A | 80 A | 100 A |
| Idle Power | 50W | 50W | 50W | 50W |
| BMS Port | Available | Available | Available | Available |
| CAN Port | Available | Available | Available | Available |
| Inverter Dimension DxWxH | 455*295*130mm/17.9*11.6*5.1" | |||
| Pack Dimension DxWxH | 580*380*220mm/23*15*9" | |||
| Net Weight | 11.5KG/25.3lbs | 11.5KG | 11.5KG | 11.5KG |
| Gross Weight | 13.5KG/29.8lbs | 13.5KG/29.8lbs | 13.5KG/29.8lbs | 13.5KG/29.8lbs |
| Humidity | 5% to 95% Relative Humidity (Non-condensing) | |||
| Operating Temperature | ‐10℃ to 55℃(-14℉to 131℉) | |||
| Storage Temperature | ‐15℃ to 60℃(5℉to 140℉) | |||
Manual
Anonymous (verified owner) –
Compact all-in-one power management that meets specifications. 24-volt version worked well for my RV application. Recommended.
Tomohiro H. (verified owner) –
It is an all-in-one type inverter.
Switching to commercial power is automatic, and the switching speed is fast.
Solar equipment can be made compact.
The manual is also easy to understand and easy to install.
I would be happy if a 200v product also appeared.
